• Model Name: IntraVue 900 AI
• Scanning Technology: Optical 3D imaging
• Scan Window Size: 15.5 × 17 mm
• Scanner Size: 264.5 × 38 × 46.5 mm
• Cradle Size: 132 × 64 × 72 mm
• Handpiece Weight: 260 g
• Cradle Weight: 540 g
• Power Input: 12V, 2.0A DC
• Electrical Classification: Class II, non-AP/APG
• Software Compatibility: BLZ IntraoralScan

Scanning Performance

• Scanning Speed: < 30 sec per arch
• Scanning Accuracy: ±20 μm precision
• Field of View: 16 × 12 mm
• Depth of Field: 25 mm
• Output Formats: STL / OBJ / PLY
• Image Sensor: Dual high-resolution cameras
• Calibration Tool: 1 piece included

System Requirements

• Operating System: Windows 10 (64-bit) or higher
• Processor: Intel Core i5 (11th Gen) or above
• Graphics Card: NVIDIA RTX 3060, 6GB or higher
• RAM: Minimum 16 GB
• Storage: 512 GB SSD or above
• USB Ports: 2 × USB 3.0 minimum

Operating Conditions

• Temperature Range: 10°C – 30°C
• Humidity Range: 10% – 85% RH
• Air Pressure: 70 kPa – 106 kPa
• Storage & Transportation
• Temperature Range: -25°C – 60°C
• Humidity Range: 10% – 85% RH
• Air Pressure: 70 kPa – 106 kPa

Electromagnetic Compatibility (EMC)

• Electrostatic Discharge: ±8 kV contact / ±15 kV air
• Electrical Fast Transients: +2 kV at 100 kHz
• Surge Protection: ±0.5 kV / ±1 kV line-to-line
• RF Conducted Disturbance: 3V (0.15–80 MHz), 6V ISM bands
• Voltage Dips: 0% UT (0.5–1 cycle), 70% UT (25/30 cycle)
• Voltage Interruptions: 0% UT (250/300 cycle)

Connectivity & Interface

• USB Interface: Type-C & USB 3.0 Type-A
• Data Transfer: Real-time USB 3.0
• Indicator Light: Blue (power on), Green (ready to scan)
